4G Module A7670 Series
Technology LTE/GSM/GPRS/GNSS
GSM: 900/1800MHz
GPS Module L76K（GPS+BDS）Dual Mode Positioning
Receiver 33 Channel
Tracking sensitivity -165 dBm
Accuracy < 2.5m CEP
Hot start < 1 s
Cold start < 35 s
Input Voltage Range DC 9 – 100V/1.5A
Back-up Battery 300mAh Li-Ion Battery
Digital Inputs 1 Digital Input (for ACC Detection)
Digital Outputs 1
GSM Antenna Built-in FPC
GPS Antenna Built-in Ceramic Antenna（25 X 25 X 4mm）
USB 2.0 Micro-USB
LED indication 1 blue and 1 green LED indicator light each, built-in, visible from the outside due to light transmission
SIM Nano SIM Card
Working temperature -20℃~80℃
